GYS TITANIUM 401 AC/DC Three-Phase Water-Cooled TIG Welder Package (Ref: 088092)

Product Overview

The GYS TITANIUM 401 AC/DC Water-Cooled Package is an elite, industrial-grade heavy-duty multi-process inverter power source designed to deliver exceptional power, pinpoint accuracy, and rugged reliability for high-demand welding configurations. Engineered for professional users with the highest manufacturing standards, this heavy fabrication platform runs on a three-phase 400V power supply and delivers an adjustable output from 3A up to a massive 400A. It provides premium, consistent arc quality on all primary metals—including mild steel, stainless steel, aluminium, copper, and titanium.

While the standalone unit treats cooling as an optional extra, this dedicated commercial package includes an integrated high-capacity liquid cooling unit and an industrial water-cooled TIG torch. This package delivers a phenomenal 100% duty cycle at full 400A at 40°C across both TIG and MMA operations, enabling uninterrupted high-amperage production runs on thick structural sections. Navigated via an expansive 7-inch XXL digital display screen, it represents the absolute benchmark for premium, defect-free industrial TIG execution.

7 Advanced TIG Welding Modes

• DC Standard: Permits uniform direct current welding on the vast majority of ferrous materials.

• DC Pulse: Regulates thermal input precisely, significantly lowering the threat of workpiece deformation and warping on thin gauges.

• FastPulse: Delivers pulsing frequencies up to 20 kHz, preserving all metallurgical control of pulse TIG while lowering background acoustic noise levels in the shop.

• PulseInPulse: Employs a double-pulse configuration to achieve advanced precision and puddle management on critical exotic materials, including Titanium, Inconel, and Duplex steels.

• AC Standard: Optimized for clear, high-penetration welding of aluminium and its complex alloys (including Al, AlSi, AlMg, and AlMn).

• AC Pulse: Restricts heat input during alternating current applications to secure structural integrity on thin aluminium sheet assemblies.

• AC Mix: Alternates sequentially between AC and DC current to accelerate welding travel speed and optimize surface oxide cleaning.

Extended Multi-Process Stick capabilities are also integrated, running advanced MMA, MMA AC, and MMA Pulse modes with electrodes up to 8 mm.

Patented TIG WIZARD Synergic Solution

The TITANIUM 401 AC/DC features GYS’s patented TIG WIZARD synergic technology. This advanced system maximizes floor productivity when tacking or welding aluminium, steel, stainless steel, and copper sections, whether feeding a filler metal or completing autogenous welds.

The wizard interface guides operators to input data for 5 different types of joints:

• Butt joint (BW)
• Lap joint (FW)
• Inside corner (BP)
• Outside corner
• Wire splicing

For specialist automated labs and welding engineers, the integrated Wizard Lab mode unlocks full manual developer access, enabling the formulation and storage of custom, bespoke welding cycle parameters from scratch.

Expert Performance & High-Connectivity Features

• Advanced Spot & Tack Cycles: Outfitted with 4 distinct modes for spot welding, featuring Spot/Multi Spot for traditional fit-ups, and Tack/Multi Tack for ultra-precise, oxidation-free spot tracking that eliminates deformation on thin sheet materials.
• Microprocessor Puddle Control: Features E-TIG Mode, which automatically regulates the welding current to guarantee consistent penetration depth regardless of changes in the operator’s physical arc length.
• Arc-Strike Customization: Offers 3 separate ignition methods—Lift, HF, and Touch.HF (timed high-frequency ignition)—along with 4 distinct trigger operations (2T, 4T-Start, 4T-Weld, and 4T-LOG).
• Waveform Modulation: Allows operators to toggle through variable AC waveforms to optimize weld pool management, reduce ambient arc noise, and adjust tracking position, while an adjustable offset minimizes electrode wear.
• 7" XXL Color Display HMI: Fitted with a massive, multilingual digital display providing 3 distinct user interface levels (Easy, Pro, and Expert) to easily match operator competency on the shop floor.
• EN 3834 Structural Traceability: Delivers total internal tracking, logging, and validation of all completed weld beads in strict accordance with the standard EN 3834 criteria.
• High-Volume Memory & Automation: Stores up to 500 distinct customized user job configurations for rapid changeovers on recurring workshop components. Includes integrated architecture to interface with industrial robots via an optional automated connection kit.
• Synchro AC Tandem Mode: Built-in capability allowing full synchronization of multiple power sources when running high-deposition tandem welding operations.
• USB Portability Shield: Features an on-board USB port to instantly back up records, transport user profiles, load firmware changes, and toggle the switchable Voltage Reduction Device (VRD) to drop open-circuit output voltage below 35V in high-risk environments.
